JMG High Speed Linear Type Mascara Lip Gloss Filling Line

This machine is widely used for filling mascara and lip oil, eye-liner products. It can work with automatic inner wiper feeding to effect output. It is used for kinds of mascara, lip oil, and liquid eye-liner.

Dimension : 1400x850x2330mm/1400x1250x1900mm/2470x820x170mm
Voltage : 3P 220V
Power : 6 KW + 1.5 KW + 1.5 KW
Working pressure : 0.5-0.8 MPa
Company:
Email:
Message:


This machine is widely used for filling mascara and lip oil, eye-liner products. It can work with automatic inner wiper feeding to effect output. It is used for kinds of mascara, lip oil, and liquid eye-liner.


Optional Configuration:

l       Pressuring device on tank

l       Heating system on tank

20L tank made of SUS304, sanitary materials.

◆ Piston filling system driven by motor, accuracy filling.

◆ Filling 12 pcs each time.

◆ Filling model is able to select static filling or filling while falling.

◆ Filling nozzle with return function, reducing pollution for bottle mouth.

◆ Material tank with mixing device.

◆ With container detecting system, no container, no filling.

◆ With servo capping system, all parameters such as torque, speed are set on touch screen.

◆ Jaws of capping is adjustable according to the height of the container, but also by the shape of the cap to do.


Output

60~84 PCS/Min




    1.Filling Machine

                        Model

                        GEGZ-80

                        12 Nozzles Mascara Filling Machine

                        Voltage

 3P  220V

                        Current

                        30A

                        Speed

     80 pcs/min

                     Capacity

                        4800 pcs/hour

                        Powder

    6 KW

Air Pressure

                        0.5-0.8 MPa

                        Weight

                        350kg



                        NO.

                    GJ180410001-1

                        Size

                        1400x850x2330mm

        2.Wipers Inserting Machine

                            Model

                            GEYS-80

                            12 Nozzles Wipers Inserting Machine

                            Voltage

 3P  220V

                            Current

 8A

                            Speed

  80 pcs/min

                            Capacity

           4800 pcs/hour

                            Power

                            1.5KW

                            Air Pressure

    0.5-0.8 MPa

                            Weight

                            280kg



                            NO.

                            GJ180410001-2

                            Size

                            1400x1250x1900mm

        3.Capping Machine

                            Model

                            GEXG-80

                            4 Nozzles Capping Machine

                            Voltage

  3P  220V

                            Current

 8A

                            Speed

     80 pcs/min

                            Capacity

4800 Mould/Hour

                            Power

                            1.5 KW

                            Air Pressure

        0.5-0.8 MPa

                            Weight

                            450kg



                            NO.

                            GJ180410001-3

                            Size

                            2470x820x170mm
