JR-01 Automatic Rotary Nail Polish Filling Capping Machine

This machine is used for filling nail polish, perfume, essential oil, mascara, lipgloss, foundation liquid and other cosmetic products.

Dimension : 3725*1660*2120MM(L*W*H)
Voltage : AC 380V(220V),3P,50/60Hz
Power : 2KW
Working pressure : 0.6-0.8Mpa
Company:
Email:
Message:


This machine is used for filling nail polish, perfume, essential oil, mascara, lipgloss, foundation liquid and other cosmetic products.



◆ With functions of tube detection, auto tube loading, auto filling, wipers sorting, auto wipers feeding, wipers detection, auto wipers pressing, auto brush cap feeding, brush cap detection, auto capping and finished product discharging.

◆ The rotary table with magnetic cups on it which is easy for replacing.

◆ Servo filling system can easily switch between different filling modes.

◆ Tank has the functions of stirring, pressuring, heating and heat preservation.

◆ The application of the manipulator to grasp tube, wiper and brush cap ensures the stability of the whole machine.

◆ Servo capping can prevent the cap from scratching, the torque can be adjusted easily.


Model

JR-01

Out dimension

3725*1660*2120MM(L*W*H)

Voltage

AC 380V(220V),3P,50/60Hz

Power

2 KW

Air supply

0.6-0.8Mpa

Filling volume

5-30ml

Bottle diameter

15-55min

Output

40-45 pcs/min

Weight

1300kg
